Description
Product Advantages: Security: Multi-level protection, safe and reliable- Door lock safety interlock device to ensure safety
- Automatic water shortage protection, and sound and light alarm, prevent dry burning
- Pressure safety protection, overtemperature and overpressure double protection
- The PID temperature controller with digital display is adopted to realize precise temperature control
- Convenient operation, dynamic display, and detailed display of the current state in the sterilization process
- Rapid cooling mode & natural cooling mode is suitable for the sterilization of different items
- Multiple procedure modes are suitable for sterilization of different items
| · The upper cover cannot be opened under pressure, and the program cannot run until the upper cover is closed. | · Automatic protection for water shortage, and sound and light alarm. | |||
| · Self-expanding silicone rubber sealing ring has good sealing effect and long service life. | · Anti-hot design: the top cover is made of glass steel, safe and anti-hot protection. |
- Automatic protection function: over-temperature protection, over-pressure venting protection
- After sterilization, the buzzer will remind and the machine will stop automatically
- Microcomputer automatic control, arbitrary set sterilization parameters
- Automatically discharge cold air and steam after sterilization
- Hand wheel translation type quick opening door structure
- Low water level protection to prevent dry burning
- High-quality stainless-steel material
- Equipped with standard test interface
- FRP door cover anti scald protection
- Stainless steel bucket (or net basket)
- Digital display, touch button
| Product Model | VSAS-75 | |
| Nominal working pressure | 0. 22MPa | |
| Rated Functioning Temperature | 134°C | |
| Temperature Range | 50~134°C | |
| Time Range | 4~120min | |
| Rated Voltage/frequency | AC220V/50Hz | |
| Rated Power | 4.5KW | |
| Net Capacity | 75L | |
| Sterilization chamber Dimension | Ø400x625 | |
| Internal Dimension | Ø380x540 | |
| Net weight | Kg | 90 |
| Ibs | 198 | |
| Gross weight | Kg | 120 |
| Ibs | 264 | |
| Boundary Dimension | (LxWxH) mm | 525x525x1200 |
| (LxWxH) In | 20x20x47 | |
| Packing Dimension | (LxWxH) mm | 630x680x1290 |
| (LxWxH) In | 25x27x51 | |
| 20’/40’/40’H Container Load | 27/54/108 | |
| Interior Material | SUS304 | |
| Cabinet Type | Vertical (Open up) | |
| Ambient Temperature | 5~40OC | |
| Heating Type | Electric Heating Tube | |
| Cold Air Removal Method | Gravity Displacement | |
| Water-Injection Method | Manual | |
| Drainage Method | Manual | |
| Door Opening Method | Handwheel Horizontal Opening | |
| Safety protection | Anti-dry burning, over-pressure protection, over-temperature protection, over-current protection, sensor disconnection detection | |
| Sensor Type | PT100 | |
| Controller | Microcomputer | |
| Display Screen | LCD | |
| Accessories details | Manual, tray, stainless steel inner tube, cover, vent tube | |
