Description
Technical specifications
Power:
AC-DC dual-use: Use the batteries,
AC100V~240V, 50/60 Hz.
Main Unit:
Portable
Dimensions: L320xW205xH410
Weight:7.5kg
Display
- Screen Type: High-resolution display, TFT colour display
- Screen Size: 7 inches (17.7cm) diagonally
- Sweep Speed: 12.5/25/50 mm/sec
- Information: Heart Rate, Lead, Alarm On/Off, Delivered Energy
- Resolution: 800X480
ECG
- Patient Connection: 3-lead ECG cable, or 5-lead ECG cable, paddles.
- Lead Selection: Displayed on monitor, paddles, I, II, III, AVR, AVL, AVF, V.
- ECG Size: 2.5, 5, 10, 20, 30 mm/mV display on monitor.
- Heart Rate: 20-350 BPM.
- Protection: With stand 4000vAc/50Hz voltage in isolation and work against electrosurgical knife and defibrillation
Defibrillator
- Waveform: Biphasic
- Defibrillator type: Manual External Synchronous/Asynchronous Defibrillation.
- Charge Time: Less than 10 seconds to 360 Joules
- Energy Display: Monitor display indicates both selected and delivered energy.
- Charge Prompt Type: Voice and visual prompts.
- Energy Selection: Selectable at 0, 3, 5, 7, 10, 20, 30, 50, 100, 200, 300, 360 joules
- Standard Adult/Pediatric Paddles: Reusable external adult paddles (pediatric paddles integrated)
AED
- Discharge Control: Control on device front panel.
- Voice prompts and screen prompts.
- Energy Programmable Sequence:
200,300,360 Joules;
150,150,200 Joules;
50, 75, 100 Joules;
30, 30, 50 Joules;
Battery Description
- Standard Type: Li-ion battery Li1104c 11.1Vdc 4000mAh X2
- Standard Capacity: Up to 10 hours ECG monitoring or 60 full-energy discharges.
- Low Battery Indicator: Flashing low battery icon on display and Bat Indicator on the panel of defi-monitor be on
- Recharge Rate: 80% in 3 hours. 100% in 5 hours.
Built-in Recorder
- Paper: 50 mm thermal.
- Printing Method: High-resolution, thermal print head.
- Record date, time, sweep speed, waveform gain, heart rate, energy (joule) and ECG waveform
- Print mode
- HR exceed limits alarm recording
- Auto timed recording
- Real-Time Recording
- Defibrillation discharge trigger recording
- Composite Paddle
- Paddle Pallet
- Battery Cover
